| Model | FB-20 | FB-30 | FB-50 |
| Type of Laser | FIBER | ||
| Laser power | 20W | 30W | 50W |
| Laser wave length | 1064nm | ||
| Laser frequency | 0~200khz | ||
| Marking Depth | ≤2mm | ≤3mm | ≤5mm |
| Mark Range | Available in the following sizes: 70×70 mm, 110×110 mm, and 140×140 mm. | ||
| Mark Line Speed | <=7000mm/s | ||
| Character dimension | 0.15~150mm | ||
| Minimum Line Width | 0.1mm | 0.1mm | 0.15mm |
| Repeatability precision | ≤0.01mm | ||
| Laser | Pulsed Fiber Laser | ||
| Total power consumption | ≤250W | ||
| Electricity Demand | 220V50-60HZ | ||
| Focus distance | Available in 140mm and 210mm sizes | ||
| Product Speed Monitoring | Synchronous encoder or analog speed | ||
| Working Temperature | 5~45 | ||
| Cooling-down method | Air cooling | ||
| Control method | Industrial-grade embedded control (LINUX) | ||
| Touchscreen (optional) | 10.2-inch full-color touchscreen, suitable for handheld | ||
| Marking Method | Flight carving, static carving, intelligent carving | ||
| Marking Content | Text, complex graphics, one-dimensional (two-dimensional) barcodes, variable serial numbers, Dates, TXT files, RS232/TCP/IP communication data, PLT-format drawings, etc. | ||
| Supported Fonts | True Type, Single Line Body, Dot Matrix Font | ||
| Marking Advantage | Online editing, large-format engraving, orientation engraving, precise recording, quick switching, intelligent memory triggering | ||
| Net Weight / Gross Weight | 87.5kgs/84kgs | ||
| Product/Packaging Size | 655*780*1420mm/1600*700*390mm | ||
